DAE AMR130-RN Kit - Automatic Meter Reading Module with RF Output for Water Meters | Remote Water Usage Monitoring for Smart Homes & Utilities

Product Description

AMR130-RN KIT Auto Meter Reading Module with RF Output Size 3.74-inch x 2.48-inch x 2.12-inch LED Indicators RF TX/RX LED, Pulse input LED Communication RF 900~930MHz (Default: 915MHz) Auxiliary Power DC 12-15V / 5.4VA Operating Temperature -40 to 70˚C (-40 to 158˚F) Operating Humidity 0 to 90% RH (non-condensing) Indoor use only, DAE B1725 watertight NEMA 4 enclosure is available for outdoor use. RF Transmission Rate 0.3~62.5 ( Default: 2.4kbs ) Transmitter RF Output Power 22dBm, 17dBm,13dBm, 10dBm Antenna Type Suction type, 3.5dBi Transmission Range 5 km (Clear weather, open area without obstacles, antenna 2 meters above the ground.) Settable Parameters Address 0~254; Baud Rate 1200, 2400, 4800, 9600 bps (default 9600 bps); Decimal Places: 0, 0.0, 0.00 (default 0); Pulse Divider: 1, 4, 8, 10, 16, 32, 64 (default 1) Mount Din Rail, TS35/7.5 or TS35/15 Certification FCC certified Memory Non-volatile memory retains metering data during power failure For the buyers outside of USA In addition to the tax, the carriers may charge brokerage fee. The accessories (included in the listing) are the Power Adapter (output 12V DC, input 120V AC), Din Rail (to install AMR130-RN to the wall). Please follow the wiring connection below. Cloud Metering for Water 1 AMR130AN KIT + 1 CC2030 KIT 1 DAE CC2030 KIT Gateway + 1 AMR130AN KIT can read 1 water meter with pulse output (like DAE AS200U-75P, MJ-75, PD-100, V-75P, VM-75P and WP-300P) remotely with cell phone, PC and generate billing report. One CC2030 Gateway can monitor 20 meters ( water, electricity, and gas). 1 AMR130-RN KIT+1WSC500A + 1 CC2030 KIT For existing building, hard to draw cable between AMR130AN and CC2030, please choose 1 AMR130-RN KIT + 1 CC2030 KIT + 1 WSC500A to connect them wirelessly. For remotely monitoring a water meter in an area without power like the one in the farm, please choose CC2030 KIT+AMR130RB+WSC500A to connect Battery-Powered AMR130RB (close to water meter) and CC2030 (close to your router) wirelessly. 1 AMR KIT + 1 CC2030 KIT For monitoring up to 16 water meters remotely, you will just need 1 AMR KIT + 1 CC2030 KIT. 1 AMR KIT+2 WSC500A + 1 CC2030 KIT For existing building, hard to draw cable between AMR (close to water meter) and CC2030 (close to your router), please choose 1 AMR KIT + 1 CC2030 KIT+ 2 WSC500A RF Converters to connect them wirelessly. Back Flow Prevention Valve You must have back-flow-prevention valve in your piping system, or the reading of CO-10, Cell phone/PC may be more than the reading of water meter due to the backflow. Most of US piping system have back-flow-prevention valve. If not, please install one or refer to Non-Return-Valve (like NRVAS-75 for AS200U-75P) in DAE Controls Website, an in-expensive backflow prevention valve to be installed at the outlet of water meter. UL2464 Shielded Twisted Pair Cable with Drain Wire, 24 AWG To securely transfer metering data for DAE Cloud Metering Solutions on Water, please use UL2464 cable to extend connection between water meters (have about 4 ft pulse cable) and AMR130-RN, or reading of Cell phone/PC may be more than the reading of meter due to exterior interference. DAE B1725 Plastic watertight NEMA 4 IP66 Universal Electrical Enclosure with Mounting Plate Indoor use only, DAE B1725 watertight enclosure is available for outdoor use. AMR130AN KIT AMR130-RN KIT AMR130A KIT AMR KIT AMR130RB Add to Cart Add to Cart Add to Cart Add to Cart Add to Cart Customer Reviews 4.1 out of 5 stars 8 4.1 out of 5 stars 8 4.1 out of 5 stars 8 4.1 out of 5 stars 8 4.1 out of 5 stars 8 Price $149.00$149.00 $172.00$172.00 $202.00$202.00 $502.00$502.00 $192.00$192.00 Support 1 Water meter ✓ ✓ ✓ no data ✓ Support up to 16 Water Meters no data no data no data ✓ no data Wireless no data ✓ no data no data ✓
